HBM MGCplus - DC Voltage Sources

Connection
DC voltage sources
MGCplus A0534-30.0 HBM: public 63
4.3.13 DC voltage sources
8
15
A
D
AP01i AP03i
1
8
9
15
G
D
E
B
F
C
A
(-)
(+)
U
Cable shield
6
C
Supply voltage zero
1)
1)
With a potential-free DC voltage source you must connect pin 15 with pin 6.
Hsg. Hsg.
Maximum input voltage against
ground = 12V
