Introduction
MGCplus housing designs
MGCplus A0534-30.0 HBM: public 23
3.6 Possible amplifier/connection board combination
Single-channel amplifier
AP01i
ML01B ML10B ML30B ML38B ML55B ML60B
R
1,4,5,B1
R
1,4,5,B1
1,4,5,B1 1,4,5,B1
AP03i
TEDS
TEDS
SG full bridge circuit
SG half bridge circuit
SG quarter bridge circuit
Inductive half bridge
Inductive full bridge
Voltage
Current
T3...T10
Torque / rotational speed
T3...T10
Pulse counter, frequency
1,4,5,B1
R
Piezoresistive
transducer
Torque
T1, T4, T5, TB1
AP14
Potentiometric
transducers
AP17
1)
For the combination of ML55B with AP14, a one-time zero calibration must always be
performed after setting up the measurement chain.
