Connection
Torque flange T10 series, T40 series
54 A0534-30.0 HBM: public MGCplus
Torque measurement signal, frequency output (+)
Ground
Plug 1
Md
Cable shield
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye= yellow; gn= green; gy= gray
1
2
10
AP460i
Torque measurement signal, frequency output (-)
Hsg.
7/5
4
1
w
h
r
d
gn
g
y
ye
1
2
3
4
5
67
8
910
Information
The torque flanges must be powered externally.
