Additional functions
Remote control (single-channel modules only)
MGCplus A0534-30.0 HBM: public 193
Level 0VLevel 5VFunction
REMT Remote control con
tacts inactive
Remote control contacts active
INT All connection boards:
Integrator is started with the transition from 5V - 0V. The
transition from 0V - 5V stops integration.
AP13i connection board
Parameter set selection
PSEL1 PSEL2 PSEL4 Selected parameter set
0 0 0 1
1 0 0 2
0 1 0 3
1 1 0 4
0 0 1 5
1 0 1 6
0 1 1 7
1 1 1 8
Tab. 8.1
0: Remote control contacts not activated; level 5 V
1: Remote control contacts activated; level 0 V; connected to digital ground
