Display
F keys
MGCplus A0534-30.0 HBM: public 233
Function Effect
Tare Taring is triggered.
Zero balance A zero balance is being performed.
Delete memory Peak-value memory is deleted.
Zero/Cal/Measure Switching between zero signal, calibration signal and measurement signal.
Autocal Autocalibration is turned on/off.
LED Status/Level Switching between LED display "Status" and "Level".
Limit value level The "Limit value level" menu is called.
Remote/Local Turn remote control on/off.
Shunt On/Off Turn shunt (transducer, AP14) on/off.
Start/Stop display The current measured value in the display is "frozen" (pause function).
Load next P-set The next parameter set of the amplifier(s) is loaded (1...8).
Load previous P-set The previous parameter set of the amplifier(s) is loaded (1...8).
Switch unit Switches between the basic unit (mV/V), user unit (for example kg) and analog
output (V).
Start/Stop integration Integration of peak values is turned on/off.
Start/Stop recording Recording of measured values is turned on/off.
Load rec. Parameters Parameter sets are loaded from RAM (parameter set 0) or the hard disk param
eter sets 1...16).
Load rec. Comments Recording comments are loaded from the hard disk.
Linearization On/Off Turn linearization of the characteristic curve of the transducer on/off.
TEDS The transducer data is read into the amplifier
Tab. 9.1 Assignment abbreviations of the function keys
