System
Recording series of tests
274 A0534-30.0 HBM: public MGCplus
Comments
Offset Type Content
Offset+0 char[80] comment of measurement
Offset+80 char[80] comment of active parameter set
Slot specific data
Offset Type Content
Offset+0 INT32 Number of used slots
For each used slot static and dynamic slotparameter
Offset Type Content
Offset+0 INT32 Slotnumber (Channel number)
Offset+4 INT32 No. of Bytes of the Block with static slotparameter
Offset+8 INT8[15] serial number of amplifier
Offset+23 INT8[15] serial number of AP 1 (Slot A)
Offset+38 INT8[15] serial number of AP 2 (Slot B)
Offset+53 INT16 AP code (e. g. 5500 for AP01)
Offset+55 INT16 SAD1 Code
Offset+57 INT16 SAD2 Code
Offset+59 INT8[15] User Info (IDS?299) from AP (with PRG800,299,"String" prog.)
Offset+74 INT8[] filled until size (see Offset+4 ...)
Offset+0 INT32 No. of Bytes of the blocks with dynamic slot parameters
Offset+4 INT32 length of the following parameter
Offset+8 INT32 Type of the following parameter (IDS Code)
Offset+12 INT8[] Parameters
Offset+x INT32 length of the next parameter.......etc.È
After data offset (LONG value from byte 24, see header) the measured data
is available in the following form:
for channel
for signal
measured value
end
end
