Connection
DC voltage sources
MGCplus A0534-30.0 HBM: public 65
(-)
(+)
U
Maximum input voltage against
ground = +50V
AP801
Hsg.
(-)
(+)
AP801S6
Hsg.
3
41
2
1
2
3
4
Supply voltage 8V/16V
*)
Power supply 0V
U
*) For information on switching the supply voltage see next page
