147
Saving Measurement Data
The following parameter symbols are used when saving text les:
Parameters Description
Symbol used when
saving text les
Z Impedance (
Ω
) Z [ohm]
Y Admittance (S) Y [S]
θ
Impedance phase angle (°) PHASE [deg]
Rs Effective resistance= ESR (
Ω
)(Equivalent series resistance) RS [ohm]
Rp Effective resistance (
Ω
) (Equivalent parallel resistance) RP [ohm]
Cs Capacitance (F) (Equivalent series capacitance) CS [F]
Cp Capacitance (F) (Equivalent parallel capacitance) CP [F]
D Loss factor= tan
δ
D
G Conductance (S) G[S]
X Reactance (
Ω
) X [ohm]
Ls Inductance (H) (Equivalent series inductance) LS [H]
Lp Inductance (H) (Equivalent parallel inductance) LP [H]
Q Q-factor Q
B Susceptance (S) B [S]
OFF No display No symbol
8
Using USB Flash Drive (Saving and Loading Data)
