General Specications
Limit function
Function Sets limits (limit values) on the voltage that can be applied to the sample or
the current that can ow to the sample.
Operating mode OFF/ON
Current limit During open-terminal voltage mode or constant-voltage mode operation
Limit range: 0.01 mA to 100.00 mA
Limit accuracy: Monitor current accuracy specications and software control
range (±1%±10 µA)
Voltage limit During constant-current mode operation
Limit range: 0.01 V to 5.000 V
Limit accuracy: Monitor current accuracy specications and software control
range (±1%±10 mV)
Default setting OFF
Output impedance (H
CUR
terminal, measurement frequency 1 kHz)
Normal mode 100
Ω
±10
Ω
*
Low impedance high accu-
racy mode
10
Ω
±2
Ω
*: The output resistance and termination resistance will be set to 50
Ω
(The output resistance is the resistance
connected to the H
CUR
terminal, and the termination resistance is the resistance connected to the L
CUR
termi-
nal) when measuring under the following conditions with the cable length set to 1 m, 2 m, or 4 m:
All measurement frequencies for the 10 k
Ω
range to the 100 M
Ω
range
Measurement frequencies from 1.0001 MHz to 8 MHz for the 100 m
Ω
range to the 1 k
Ω
range
