190
General Specications
Measurement range
Measurement range 10 ranges (100 m
Ω
, 1
Ω
, 10
Ω
, 100
Ω
, 1 k
Ω
, 10 k
Ω
, 100 k
Ω
, 1 M
Ω
, 10 M
Ω
,
100 M
Ω
)
• Dened for impedance Z.
• Other measurement parameters are calculated from Z and
θ
values.
See "Appx. 1 Measurement Parameters and Calculation Formula"
(p. Appx.1).
• See the table below for the accuracy guaranteed range and the selection
of auto ranges for each range.
Range selection method Selected with the HOLD setting, AUTO setting, or judgment synchronization
setting.
HOLD setting The range is set manually.
The measurement range is xed.
AUTO setting The optimal range is set automatically.
Judgment synchronization
setting
The optimal range for the judgment standards being used for comparator or BIN
measurement is set automatically.
Default setting AUTO, judgment synchronization OFF
Range Guaranteed accuracy range AUTO ranging range
100 M
Ω
8 M
Ω
to 200 M
Ω
8 M
Ω
or more
10 M
Ω
800 k
Ω
to 100 M
Ω
800 k
Ω
to 10 M
Ω
1 M
Ω
80 k
Ω
to 10 M
Ω
80 k
Ω
to 1 M
Ω
100 k
Ω
8 k
Ω
to 1 M
Ω
8 k
Ω
to 100 k
Ω
10 k
Ω
800
Ω
to 100 k
Ω
800
Ω
to 10 k
Ω
1 k
Ω
80
Ω
to 10 k
Ω
80
Ω
to 1 k
Ω
100
Ω
8
Ω
to 100
Ω
8
Ω
to 100
Ω
10
Ω
800 m
Ω
to 10
Ω
800 m
Ω
to 10
Ω
1
Ω
80 m
Ω
to 1
Ω
80 m
Ω
to 1
Ω
100 m
Ω
1 m
Ω
to 100 m
Ω
0
Ω
to 100 m
Ω
• The guaranteed accuracy range differs depending on the measurement conditions (See p. 213.)
• Outside the selection of ranges, measured values whose accuracy is not guaranteed are displayed on the
screen.
• Outside the A/D input range, OVERFLOW or UNDERFLOW is displayed on the screen.
Low Z high accuracy mode
Function Increases the measurement current using 10
Ω
output resistance (to a
maximum of 100 mA and a maximum applied voltage of 1 V). As a result,
the measurement precision increases.
Operation mode OFF/ON
Target ranges 100 m
Ω
, 1
Ω
, 10
Ω
range
Frequency range 4 Hz to 1.0000 MHz
Default setting OFF
