Function specications
Waveform averaging
Function • Allows you to set the number of measurement waveforms for each mea-
surement frequency band as desired.
• Measurement precision increases as the number of waveforms increases,
while measurement speed increases as the number of waveforms decreases.
Operation mode OFF/ON
Valid setting range See table below.
Default setting OFF
Measurement frequency
Waveform averaging
function ON
Waveform averaging function OFF
Valid setting range FAST MED SLOW SLOW2
DC (Power supply frequency 50 Hz) 1 to 2000 5 100 500 2000
DC (Power supply frequency 60 Hz) 1 to 2400 6 100 600 2400
4.00 Hz to 10.00 Hz 1 to 4 1 2 3 4
10.01 Hz to 39.99 Hz 1 to 10 1 2 5 10
40.00 Hz to 99.99 Hz 1 to 40 1 2 5 40
100.00 Hz to 300.00 Hz 1 to 50 1 2 5 50
300.01 Hz to 500.00 Hz 1 to 200 1 2 10 200
500.01 Hz to 1.0000 kHz 1 to 300 1 5 20 300
1.0001 kHz to 2.0000 kHz 1 to 600 1 8 40 600
2.0001 kHz to 3.0000 kHz 1 to 1200 2 12 60 1200
3.0001 kHz to 5.0000 kHz 1 to 2000 3 20 100 2000
5.0001 kHz to 10.000 kHz 1 to 3000 5 40 200 3000
10.001 kHz to 20.000 kHz 1 to 1200 2 16 80 1200
20.001 kHz to 30.000 kHz 1 to 480 1 6 24 480
30.001 kHz to 50.000 kHz 1 to 800 1 10 40 800
50.001 kHz to 100.00 kHz 1 to 1200 2 16 80 1200
100.01 kHz to 140.00 kHz 1 to 2400 4 32 160 2400
140.01 kHz to 200.00 kHz 1 to 2400 4 32 160 2400
200.01 kHz to 300.00 kHz 1 to 960 2 12 48 960
300.01 kHz to 400.00 kHz 1 to 1600 2 20 80 1600
400.01 kHz to 500.00 kHz 1 to 1600 2 20 80 1600
500.01 kHz to 700.00 kHz 1 to 2400 4 32 160 2400
700.01 kHz to 1.0000 MHz 1 to 2400 4 32 160 2400
1.0001 MHz to 1.4000 MHz 1 to 960 2 14 64 960
1.4001 MHz to 2.0000 MHz 1 to 960 2 14 64 960
2.0001 MHz to 3.0000 MHz 1 to 1440 3 24 96 1440
3.0001 MHz to 4.0000 MHz 1 to 2400 4 40 160 2400
4.0001 MHz to 5.0000 MHz 1 to 2400 4 40 160 2400
5.0001 MHz to 6.0000 MHz 1 to 4000 8 64 250 4000
6.0001 MHz to 8.0000 MHz 1 to 4000 8 64 250 4000
