200
Function specications
• Spot correction
Function Acquires correction values for the set measurement frequencies.
Maximum number of
settings
5 points
Valid frequency setting
range
DC, 4 Hz to 8 MHz
• OFF (Default setting)
Function Disables short correction data.
Load correction
Function Measures a reference sample whose measured value is known and then
calculates the correction coefcient. The coefcient is used to correct mea-
sured values.
Number of sets of
correction conditions
Up to 5
Correction correction
settings
Correction frequency, correction range, correction signal level, DC bias,
parameter type, reference value 1, reference value 2
Seven settings can be congured for each set of correction conditions.
Calculation equation
Z
=(
Z
before correction )×(
Z
correction coefcient)
θ
=(
θ
before correction)+(
θ
correction value)
Z
correction coefcient=
(
Z
reference value)
(accutual data of
Z
)
θ
correction value =(
θ
reference value)-(accutual data of
θ
)
Operation mode OFF/ON
Default setting OFF
Cable length correction
Function Corrects measurement errors caused by the effects of the measurement
cable.
Cable length settings 0 m, 1 m, 2 m, 4 m
Default setting 0 m
Correlation correction
Function • Corrects measured values using user-congured correction coefcients
(using user-congured correction coefcient A and correction coefcient B).
• Corrected measured values are calculated using the following equation:
(Measured value after correction)=A×(measured value)+B
Operation mode OFF/ON
Correction coefcient A
setting range
-999.999 to 999.999
Correction coefcient B
setting range
-9.99999 G to 9.99999 G
Default setting OFF
(Correction coefcient A: 1.000, Correction coefcient B: 0.00000)
