202
Function specications
Saving screenshots
Function The SAVE key saves the currently displayed screen.
Data format BMP le format (256 colors or 2-color monochrome)
File name Generated automatically based on the time and date and given the exten-
sion “BMP.”
Saving instrument settings
Function • Saves settings information as a settings le on the FILE screen.
• Allows you to load previously saved settings les and restore their settings
on the FILE screen.
File name Generated automatically based on the time and date and given the exten-
sion “SET.”
Saving all settings (All save function)
Function • Saves settings information including panel save content as a settings le
on the FILE screen.
• Allows you to load settings les including panel save content that were
saved using the all save function and restore their settings on the FILE
screen.
File name Generated automatically based on the time and date and given the exten-
sion “SET” for setting les (panel save extension is “PNL”).
External control (using the EXT I/O connector)
Input and output signals
Function • Switches between judgment mode and BCD mode.
• In BCD mode, comparator/BIN judgment results are not output.
• BCD output is only enabled in LCR mode.
• BCD output includes the No. 1 and No. 3 parameters.
Judgment mode
Function Outputs comparator/BIN judgment results.
Input signal TRIG
― ―――
, LD0
―――
to
――
LD6
―――
, LD_VALID
― ― ― ― ―――
Output signal EOM
―――
, INDEX
―― ― ――
, ERR
―――
, HI
――
, IN
――
, LO
――
, AND
―――
, BIN1
――― ―
to BIN10
――― ――
BCD mode
Function Generates BCD output for the No. 1 and No. 3 parameter measured values.
Input signal TRIG
― ―――
, LD0
―――
to
――
LD6
―――
, LD_VALID, C1
―― ――――― ――
, C2
――
Output signal EOM
―――
, INDEX
―― ― ――
, ERR
―――
, D4-3
―― ―
to D4-0
―― ―
, D3-3
―― ―
to D3-0
―― ―
, D2-3
―― ―
to D2-0
―― ―
, D1-3
―― ―
to D1-0
―― ―
Trigger enable function
Function Allows you to set whether to enable trigger input from EXT I/O during mea-
surement (starting when the trigger is received and while EOM
―――
is being
output as HI).
Operation mode OFF/ON
OFF: Disabled; ON: Enabled
Default setting ON
