Measurement Range and Accuracy
No. Frequency band
Measurement speed coefcient
16 8 4 2 1
19 300.01 kHz to 400.00 kHz 1 2 to 19 20 to 79 80 to 1599 1600
20 400.01 kHz to 500.00 kHz 1 2 to 19 20 to 79 80 to 1599 1600
21 500.01 kHz to 700.00 MHz 1 to 3 4 to 31 32 to 159 160 to 2399 2400
22 700.01 kHz to 1.0000 MHz 1 to 3 4 to 31 32 to 159 160 to 2399 2400
23 1.0001 MHz to 1.4000 MHz 1 2 to 13 14 to 63 64 to 959 960
24 1.4001 MHz to 2.0000 MHz 1 2 to 13 14 to 63 64 to 959 960
25 2.0001 MHz to 3.0000 MHz 1 to 2 3 to 23 24 to 95 96 to 1439 1440
26 3.0001 MHz to 4.0000 MHz 1 to 3 4 to 39 40 to 159 160 to 2399 2400
27 4.0001 MHz to 5.0000 MHz 1 to 3 4 to 39 40 to 159 160 to 2399 2400
28 5.0001 MHz to 6.0000 MHz 1 to 7 8 to 63 64 to 249 250 to 3999 4000
29 6.0001 MHz to 8.0000 MHz 1 to 7 8 to 63 64 to 249 250 to 3999 4000
E: Coefcient of the measurement cable's length
The coefcient of the measurement cable's length is shown in the table below.
Measurement cable's length 0 m 1 m 2 m 4 m
Coefcient 1 1.5 2 3
The settable range for frequency varies with the measurement cable’s length.
Cable length Settable range for frequency
0 m Up to 8 MHz
1 m Up to 8 MHz
2 m Up to 2 MHz
4 m Up to 1 MHz
F: DC bias coefcient
The DC bias coefcient is shown in the table below.
DC bias coefcient OFF ON
Coefcient 1 2
G: Temperature coefcient
The operating temperature coefcient is shown in the table below.
(When the operating temperature (t) is 23°C±5°C, use a coefcient of 1.)
Operating temperature t [°C]
Coefcient 1+0.1×|t-23|
10
