214
Measurement Range and Accuracy
C: Measurement level coefcient
The measurement level coefcient is shown in the table below.
• DC measurement (DC resistance measurement)
Measurement level 1 V
Coefcient 1
• AC measurement
Measurement level 0.010 V to 0.999 V 1 V 1.001 V to 5 V
Coefcient 1+0.2/V
*
1 1+2/V
*
*: V is measurement level setting value (open voltage (V) mode equivalent).
D: Measurement speed coefcient
The measurement speed coefcient is shown in the table below.
Measurement speed FAST MED SLOW SLOW2
Coefcient during DC measurement
(DC resistance measurement)
4 3 2 1
Coefcient during AC measurement 8 4 2 1
Coefcient during waveform averaging function operation (See table below.)
No. Frequency band
Measurement speed coefcient
5 4 3 2 1
1 DC (line frequency 50 Hz) 1 to 4 5 to 99 100 to 499 500 to 1999 2000
1 DC (line frequency 60 Hz) 1 to 5 6 to 99 100 to 599 600 to 2499 2400
No. Frequency band
Measurement speed coefcient
16 8 4 2 1
2 4.00 Hz to 10.00 Hz - 1 2 3 4
3 10.01 Hz to 39.99 Hz - 1 2 to 4 5 to 9 10
4 40.00 Hz to 99.99 Hz - 1 2 to 4 5 to 39 40
5 100.00 Hz to 300.00 Hz - 1 2 to 4 5 to 49 50
6 300.01 Hz to 500.00 Hz - 1 2 to 9 10 to 199 200
7 500.01 Hz to 1.0000 kHz - 1 to 4 5 to 19 20 to 299 300
8 1.0001 kHz to 2.0000 kHz - 1 to 7 8 to 39 40 to 599 600
9 2.0001 kHz to 3.0000 kHz 1 2 to 11 12 to 59 60 to 1199 1200
10 3.0001 kHz to 5.0000 kHz 1 to 2 3 to 19 20 to 99 100 to 1999 2000
11 5.0001 kHz to 10.000 kHz 1 to 4 5 to 39 40 to 199 200 to 2999 3000
12 10.001 kHz to 20.000 kHz 1 2 to 15 16 to 79 80 to 1199 1200
13 20.001 kHz to 30.000 kHz - 1 to 5 6 to 23 24 to 479 480
14 30.001 kHz to 50.000 kHz - 1 to 9 10 to 39 40 to 799 800
15 50.001 kHz to 100.00 kHz 1 2 to 15 16 to 79 80 to 1199 1200
16 100.01 kHz to 140.00 kHz 1 to 3 4 to 31 32 to 159 160 to 2399 2400
17 140.01 kHz to 200.00 kHz 1 to 3 4 to 31 32 to 159 160 to 2399 2400
18 200.01 kHz to 300.00 kHz 1 2 to 11 12 to 47 48 to 959 960
