Judging Measurement Results
Percentage setting
• The actual operation performed internally is to calculate the upper limit comparison value (or lower limit
comparison value) using the following formula and then compare it to the measured value to make a judg-
ment. To set an upper limit comparison value (or lower limit comparison value) that is less than the refer-
ence value, give the percent setting a negative sign.
Upper limit comparison value= reference value + |reference value| ×
100
Percentage set value
Lower limit comparison value= reference value + |reference value| ×
100
Percentage set value
Deviation percent setting
• The measurement values are displayed in deviations (
Δ
%) from the reference value.
• The following equation is used to calculate the
Δ
% value.
Δ
%=
|reference value|
measurement value - reference value
×100
3
Performing Measurements in LCR Mode
