Table 4.3.1
Pin
Signal
1 DC+
2
RGP
3
RGS
4
DC-
B. D1-N-90
Figure 4.3.2 Connector: PC 16/4-STF-10.16 (1967472)
Table 4.3.2
Pin
Signal
1 DC+
2
RG+
3
RG-
4 DC-
(2) Wiring example
A. D1-N-09/18/36 servo drive
a. Only the internal regenerative resistor (50 Ω/150 W) is used.
Figure 4.3.3
b. Both the internal regenerative resistor and external regenerative resistor are used.
(Parallel connection)
Figure 4.3.4
1
2
3
4
