D1-N Series Servo Drive User Manual Servo Drive Configuration
HIWIN MIKROSYSTEM Corp. 5-11
MD17UE01-1906
Figure 5.2.1.1
(2) Linear motor
A. Motor parameters
Select the model of HIWIN linear motor to display and set motor parameters.
B. Operation parameter
Moving mass: Set the load mass of motor, including forcer and its housing. (Unit: Kg)
Motor parameter
setting area
Operation parameter
setting area
