Panther System
®
Operator’s Manual
AW-17791-001 Rev. 002 (EN)
132
System Operation
LED Color Meaning
Flashing
Red
Reagent Bay Lane is in an error state.
Table 57. Reagent Bay Lane LED Status Color Legend (Continued)
Sample Bay Lane LEDs
Eight (8) LED indicators are located on the top of the Sample Bay Door. The
Sample Bay Lane LEDs change color according to the following table.
LED Color Meaning
Off
Sample Bay Lane is empty or all test orders have
been pipetted from the loaded Sample Rack.
Flashing
Green
Sample Bay Lane is available for loading.
Green
Samples are loaded and available for further
processing.
Red
Samples in rack are currently being pipetted
Flashing
Red
Sample Bay Lane is in an error state.
Table 58. Sample Bay Lane LED Status Color Legend
Tip Drawer, TCR Door, and MTU Input Queue LEDs
One (1) LED indicator is located on the top of each Tip Drawer and the TCR
Door. One (1) LED indicator is also located on the front of the MTU Input Queue.
These LEDs change color according to the following table.
LED Color Meaning
Green
The drawer or door is unlocked.
Red
The drawer or door is locked.
Table 59. Tip Drawer, TCR Door, and MTU Input Queue LED Status
Color Legend
