Overview
Location Description
4. Auto Detect 1 Pump
5. Auto Detect 2 Pump
6. Deactivation Pump (Peristaltic)
7. TCR Carousel
8. Sample Bay
9. Tip Drawer 1
10. Tip Drawer 2
11. Reagent Bay
12. Reagent Barcode Reader
Table 16. Panther Upper Bay Descriptions (Continued)
Reagent Bay
Figure 7. Reagent Bay
The Reagent Bay is a liquid-cooled storage bay that holds up to four (4) racks of reagents.
The internal reagent barcode reader identifies the reagent racks and reagent bottles as
they are loaded into the instrument. The reagents are housed in a cooled environment for
extended stability.
