Overview
Figure 17. Status Panel (Example)
Status Panel Bars
The Status Panel Bars within the Status Panel are used to load consumables, manage
waste and fluids, and to track inventory.
Status Bar Meaning of Information on Status Bar
Tip Count Select this bar to load tips.
MTUs Select this bar to load MTUs.
Waste Select this bar to access the Waste Management
screen.
Fluid Kit A Select this bar to access the Universal Fluid Bay
screen.
Fluid Kit B Select this bar to access the Universal Fluid Bay
screen.
Table 24. Status Bar Updates
