Parts List
Exploded Views
224 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release L
February 2017
Chart plate
Figure 10-2 is an exploded view of the Chart Plate Assembly.
Table 10-2 is a list of the associated part numbers.
12 11
7
8
9
1
3
22097
4
2
5
6
10
13
Figure 10-2 Chart plate assembly
