8-53
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
4. Remove the Trailing Cable and Carriage
Power Cable from the groove in the Top
Crane.
Installation of the new Trailing Cable
1. Mark on the Trailing Cable 42" about
65mm from the neck of the connectors
using a marker pen.
2. Install the new Trailing Cable into the Top
Crane.
65mm (2,56 inchs)
65mm (2,56 inches)
