8-52
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Re
mo
ving
the tr
aili
ng cable
fr
om the ne
w typ
e
1.
Remov
e
one T1
5 scr
ew fr
om
the T
op
Crane
.
2.
Rem
ove t
he
T
op
C
ran
e C
over by
unclipp
ing it fr
om 3 latc
hes located
underneath
.
3.
Rem
ove t
he
Top C
ran
e
Cover
.
303
