HP 4000

8-102
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
6. Install the Main PCA Cover onto the Printer.
7. Install three T-15 screws (Type A) that
secure the Main PCA cover.
8. Install the JetDirect Card (if required).
9. Install the Left Connector Cover
⇒ Page 8-
19 .
10. Install the Rear Door
⇒ Page 8-16.
2
1
