8-130
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
8. Remove one T-15 screw that secures the
small Gear.
9. Remove the small Gear from the Printer.
10. Remove the two small Platen Gears by
releasing the clips.
