HP 4000

8-131
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
11 . Remove two T-20 screws (Type Q) that
secure the Gear Bracket.
12. Remove the Gear Bracket from the Printer.
13. Remove 79 T-10 screws (Type C) that
secure the Center Platen.
