8-150
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
10
.
Remo
ve four T
-
20 sc
r
e
ws (
Ty
p
e
B
) that
sec
ure the Electr
onics Module
.
11
.
Remo
ve the Electr
onics Module f
rom the
Pri
nter
.
12
.
Rem
ove o
ne
T-
1
5
screw (
T
ype E
),
t
h
a
t
sec
ures the C
enter Guide
, fr
om underneath
the Print
er
.
401
403
