HP 4000

8-153
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
13. Remove the Drive Roller Gear from the
Printer.
14. Remove one T-20 screw (Type B) that
secures the cover on the right hand side of
the Printer.
15. Remove the Cover.
