HP 4000

8-154
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
16. Remove two T-20 screws (Type B) that
secure the cover on the left hand side of
the Printer.
17. Remove the Cover.
18. Remove three T-20 screws (Type B) that
secure the Media-Axis Motor Bracket to the
sideplate.
