FusionModule2000 Smart Modular Data Center
Installation Guide
10 Installing the Aisle Containment
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2. Facing the aisle, secure the hanging kits marked L and R respectively to the left and
right cabinets using M5x10 tapping screws, as shown by (2) in Figure 10-28.
If the hanging kit rubs against the fixing screws in the top panel of the cabinet, remove the
screws in the top panel, and secure the top panel and the hanging kit to the cabinet using
the screws.
Verify that each conversion bracket shown by (2) in Figure 10-28 is secured by at least one
screw.
3. Facing the aisle, mount the left and right door boxes respectively onto the left and right
hanging kits, verify that they are in close contact with the middle door box, and secure
them to the hanging kits using six M5x10 tapping screws, as shown by (3) in Figure
10-28.
If the gaps between door boxes are not even, adjust the leveling screws on the hanging kits (as
shown by A and B in Figure 10-29) to ensure that the left and right door boxes are in close
contact with the middle door box.
