FusionModule2000 Smart Modular Data Center
Installation Guide
12 (Optional) Installing Aisle Lights
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 12-3 Interconnecting light tubes
Preparations
Tools: Phillips screwdriver, crimping tool, wire stripper, diagonal pliers
Materials: light tube, light holder, multi-cord end terminal
Document: aisle light installation position diagram
Procedure
Step 1 Install lights.
1. Secure light holders to the skylight connecting plates using M3 screws.
Ensure that each light tube is secured by three holders.
To Next Page
