Prerequisites
● You have obtained the IP address, subnet mask, and default gateway planned
for the UPS2000-G. UPS stands for uninterruptible power system.
● The UPS2000-G is powered on.
Context
● UPSs have various versions, for which UPS WebUIs may dier. Perform
operations based on the actual WebUI.
● Connecting the UPS2000-G to the NetEco in DES and MD5 protocols poses
potential risks. Therefore, exercise caution when deciding to do so.
Procedure
Step 1 Set the IP address on the UPS2000-G.
1. Press
next to the UPS2000-G LCD.
2. Press and select Settings.
3. Press and enter the password.
The preset password is 000001. For access security, change the password after the rst
login.
4. Press , select Communication card.
5. Press to enter the IP address setting.
6. Press , set the value size by and .
7. Press
and move the cursor to Sub mask and Default GW, set Sub mask
and Default GW by using the same as the preceding steps.
8. Press ESC to exit.
Step 2 Log in to the UPS2000-G WebUI.
1. On the PC with an IP address in the same network segment as the UPS2000-
G, type https://IP address of the UPS2000-G in the address box of a browser
and press Enter.
2. Enter the user name and password for logging in to the UPS2000-G and click
Login.
The preset user name and password for the UPS2000-G are admin and Changeme,
respectively. To ensure access security, change the password after rst login.
3. Set user permissions by referring to Step 3 or Step 4 based on the site
requirements.
Step 3 Add a user and set user permissions on the WebUI (WebUI 1).
1. Choose System Settings > SNMP Settings.
2. In the SNMP area, set SNMP Version to SNMPv3 and SNMP Port to 161,
and click Submit.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 6 Adding Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 196
