v 2.3 — September 2015 Altanium Delta3
110 System Setup Screen
Date and Time Current date and time displayed on the user interface.
Time Zone Current time zone displayed on the user interface.
Automatic Daylight Saving Automatic daylight savings on/off check box.
Interval Specifies in seconds how often the process data will be sampled.
License Number License key is displayed.
Update License Upload new license file from local, USB, and network drives.
View License Display license information.
Power Deviation Toggle this parameter on or off. If this parameter is toggled on, a
power deviation will trigger a power deviation alarm.
Power Limiting Controls the maximum output power delivered to each zone.
Log Transfer Transfer data log or event log in CSV format to specified log file
destination. The entire log is transferred or a time range can be
set.
Earth Leakage Fault Enable Toggle this parameter to turn earth leakage checking on or off.
Earth Leakage Limit For ICC
2
cards, a percentage used to calculate the earth leakage
limit once the diagnostic process for a zone is complete. The
control card uses a percentage of the current measured during
the test to determine when to declare an earth leakage error.
The parameter range is 0 to 100%. The default value is 10%.
For ICC
3
cards, the value is displayed in milliamps and has an
adjustable range from 1 to 999 mA. The default value is 500 mA.
Earth Leakage Fault Limit
Default Value
The value the system will use to determine the earth leakage limit
if diagnostics have not been run on a zone. Only displayed if ICC
2
cards are installed.
The parameter range is 0.0 to 5.0 amps. The default value is 0.2
amps.
Earth Leakage Minimum Limit The minimum earth leakage limit value. Only displayed if ICC
2
cards are installed.
Display Earth Leakage Reading Enables earth leakage displays when ICC
3
cards are installed.
Circuit Overload Enable Enables or disables the circuit overload error. Displays only if ICC
3
cards are installed.
Circuit Test Enable Enables the circuit test for ICC
3
cards.
Bake Out Enable If this parameter is enabled, the system will run the bake out test
and apply a low voltage to remove the moisture in a heater if
required. Toggle this parameter on or off.
Force Bake Out Enable Toggle this parameter on or off. If this parameter is on, each zone
in the system is baked out upon startup.
Table 10-1 System Setup Screen Item Descriptions (Continued)
Item Description
