System Setup Screen 111
User Guide v 2.3 — September 2015 System Setup Screen
Bake Out Alert Enable If this parameter is enabled, the system stops and generates an
alarm for each zone with a bake-out condition that has not been
cleared during the bake out cycle.
If this parameter is disabled, the system exits the existing bake-out
cycle and continues the startup sequence.
Bake Out Limit The system uses this value to assess whether a bake-out condition
exists. Upon system startup, if any zone exceeds this limit, the
system will enter bake-out mode.
For ICC
2
cards, the parameter range is 0 to 5 amps. The default
value is 0.2 amps.
For ICC
3
cards, the parameter range is 1 to 999 milliamps. The
default value is 200 milliamps.
Bake Out Power The system uses this value during the bake out process.
The parameter range is 0 to 25%. The default value is 5%.
Bake Out Time Per Cycle Length of the bake out cycle. The parameter range is 1 to 30
minutes. The default value is 5 minutes.
Number of Bake Out Cycles The number of attempts to bake out the moisture in a heater. The
parameter range is 1 to 5. The default value is 1.
Bake Out Setpoint Specifies the bake out setpoint the zones must achieve during the
bake out process. The default value is 100°C (212°F). Displays only
if ICC
3
cards are installed.
At Bake Out Temperature
Window
During the bake out process, this parameter specifies the
threshold that all zones must achieve before the bake out cycle
value starts counting down. The default value is 5°C (9°F). Displays
only if ICC
3
cards are installed.
Heat to Bake Out Setpoint
Timeout
Specifies the amount of time the zones are given to achieve the
bake out setpoint. If the time period expires, a warning message
displays the problem and what happens when the warning
message is acknowledged. Displays only if ICC
3
cards are installed.
Display Thermocouple
Reading for Manual Zones
A global setting that controls whether the controller view screens
display the thermocouple readings for zones in manual mode.
Allow Monitor Regulation for
Selection
Enables the parameter that allows the change of the regulation
mode to “Monitor” for any zones in the Quick Set screen.
Exclude Monitor Zones from
At-Temperature
Enables the parameter that allows the exclusion of any zones set
to “Monitor” regulation from the at-temperature determination
by the system.
Auto Slave Enable Toggle this parameter on or off.
Auto Slave Power Limit This value is the limit used by the Auto Slave routine to determine
if the average power output of a candidate zone is within the
acceptable deviation of the slaved zone.
Table 10-1 System Setup Screen Item Descriptions (Continued)
Item Description
