101
7 Configuration
7.4.3 Colors
Device dialog (excerpt)
Parameter
Parameter Selection/settings Description
Analog channel 1
to
analog channel 6
Color ... Color used to display the corresponding
analog channel (graphically, numerically,
and in text form).
Digital channel 1
to
digital channel 6
Color ... Color used to display the corresponding
digital channel (graphically and in text
form).
Analog curves
background
Color ... Background color for displaying the ana-
log curves
Digital trace back-
ground
Color ... Background color for displaying the digi-
tal traces
Alarm refer. curve Color ... Color used to display an analog channel
when it leaves a tolerance band.
Alarm 1,
Alarm 2
Color ... Color used to mark the alarm in question.
Time stamp in di-
agram
Color ... Color used to display the time informa-
tion.
Grid lines in dia-
gram
Color ... Color in which the grid in the curve dia-
gram is displayed.
