175
7 Configuration
7.20.2 Batch lines
Device dialog box
Parameter
Parameter Selection/settings Description
Text left column Program name (in line 1)
Use default text or enter other text.
This parameter specifies the text in the
left column for the selected line of the
batch report.
Contents of right
column
This defines how to compose the texts in the right column of a batch report.
No entry The field remains empty.
Default text A set text – defined by the "Default text"
parameter – is used.
Selection from the text list The user can select the text from the text
list (batch texts).
After reconfiguration, the default text is
initially displayed; the user must select
the desired text from the list in the "Cur-
rent batch" visualization. The texts can
be defined in the setup program.
Selection by digital signal A text from the text list (batch texts) is
used. The selection is performed using a
maximum of 6 digital signals (text selec-
tion bits).
The texts can be defined in the setup
program.
Batch name The batch name is displayed.
Batch number ... The batch number is used along with a
text (default text). The batch number is
incremented at the end of batch report-
ing. It can be pre-assigned using the de-
vice in the parameterization menu.
Batch start Start (date and time) of batch reporting
