6.2 User interface
Menu bar
The individual functions of the setup program are launched from the menu bar.
chapter 6.3 "Menu bar functions", Page 81
(1) Menu bar (2) Toolbar
(3) Working area – navigation tree (4) Working area – display window
(5) Connection status (6) Online data
