89
6 Setup program
Print
The function enables the current settings to be printed. You can choose which parameter groups to print
and which not to print. Alternatively, printing is also possible via the File menu.
6.4.2 Create file info
The file info consists of the file info header and the file info text; and is used to describe the setup file.
The information is only stored in the setup file and not transferred to the device.
The file info header and file info text can be directly called up via the corresponding menu entry in the
navigation tree or display window.
Setup dialog box
Parameter
6.4.3 Create configuration
The device configuration is divided into three areas in the setup program:
• Configuration level
• Only setup
• Online parameters
The individual parameters and their settings are described in the relevant chapters of this operating man-
ual.
Configuration level
chapter 7 "Configuration", Page 91
Parameter Selection/settings Description
File info header
Short info Enter text Description of the setup file in short form
Programmer Enter text Name of programmer
Order code Enter text Order code
Order Enter text Order number
Extra info Enter text Additional information
File info text
File info text Enter text Exhaustive description of the setup file
