JUMO LOGOSCREEN 601 User Manual

17
2 Description
2 Description
2.1 Brief description
The JUMO LOGOSCREEN 601 paperless recorder is characterized by an intuitive, icon-based opera-
tion and visualization concept that makes it easy to operate.
Different versions of the JUMO LOGOSCREEN 601 are available for process data recording. The scal-
ability allows for flexible adaptation to various customer requirements: from the device version without
measurement input (24 process values via interface) through to different device versions with up to 6
measurement inputs (universal analog inputs), 2 analog outputs, 12 digital inputs, 12 individually switch-
able digital inputs/outputs. A relay output is available as standard. The version with FDA-compliant data
recording fulfills all requirements according to 21 CFR Part 11.
In order to display the recorded data, the JUMO LOGOSCREEN 601 features various visualizations. In
addition, the user can use the setup program to create up to 6 separate process screens – with up to
100 objects per process screen – according to his individual requirements. For batch-based processes,
a special batch recording is available which enables the storage of additional, batch-related information.
The extra code "structured text" allows for the creation of individual measurement and recording appli-
cations.
2.2 Block diagram
Setup programm
PCC, PCA3000
PCS, PCAT
Software
Internal channels
6 math channels (optional)
6 logic channels (optional)
6 counters/integrators
2 high-speed counters
ST code (optional)
Inputs/outputs
Optionen 1 und 2:
3 analog inputs,
6 digital inputs,
1 analog output
each
12 digital inputs/outputs,
incl. 2 high-speed counting inputs
(up to 12.5 kHz)
Option 3:
Display/operation
JUMO LOGOSCREEN 601
Voltage supply
Display
Operation
14.5 cm (5.7”) TFT color screen
640 x 480 pixel,
65536 colors
Touchscreen (resistive)
As standard:
24 external analog inputs and
24 external digital inputs and
14 external texts (10 batch texts,
4 event texts)
Inputs via interface
As standard:
1 relay (changeover contact)
Relay output
AC 110 to 240 V +10/-15 %,
48 to 63 Hz
AC/DC 20 to 30 V, 48 to 63 Hz
Interfaces
As standard:
1x Ethernet 10/100 MBit/s
1x USB host (flash drive)
1x USB device (setup)
1x RS232/RS485
(Modbus master/slave or
barcode scanner)
Optional:
1x PROFINET IO Device
Internal memory
(data transfer via interface
or USB flash drive)
: 1 GByte
Measurem.-data memory
