7 Configuration
182
7.22.1 Modbus slave
The device acts as a Modbus slave.
Device dialog box
Parameter
Data format Data format with which the interface is operated.
8 - 1 - no parity 8 data bits, 1 stop bit, no parity
8 - 1 - odd parity 8 data bits, 1 stop bit, odd parity
8 - 1 - even parity 8 data bits, 1 stop bit, even parity
Min response
time
0to40 to 500 ms The minimum response time is adhered
to by the Modbus slave before a re-
sponse is sent following a data request.
After receiving a response, the Modbus
master waits during this period before
sending a new request.
Line break char-
acter
(setup only)
$
Blank space
.
;
:
-
This character triggers a line break when
scanning batch texts (only for protocol =
barcode).
Parameter Selection/settings Description
Parameter Selection/settings Description
Device address 1 ... 254 Modbus device address
Timeout
monitoring
No Monitoring is not active.
Yes Monitoring is active.
