10 Online parameter (setup only)
10.6 Additional process values for online data
Additional process values to be displayed as online data are selected in this dialog ("Additional process
values" tab).
Setup dialog box
After pressing the "Edit" button (or double clicking on the relevant line), the following dialog appears; you
can then select the process value:
Parameter
Parameter Selection/settings Description
Process value Select the process value from the selec-
tor (drop-down menu)
No selection
Analog signal, digital signal, or text
The selection you make is displayed in
the online data "Selector" column along
with the complete path from the selector.
The value of the process value is shown
in the "Value" column.
Additional identifi-
er
Enter text (max. 30 characters) Individual designation of the process val-
ue
The text is shown in the online data
"Identifier" column.
Unit Enter text (max. 6 characters) Process value unit
The text is shown in the online data
"Unit" column.
