43
5 Operation
5.3.1 Alarm list
The alarm list shows all alarms that are present in their order of occurrence. If an alarm is no longer pres-
ent, its entry is automatically removed from the alarm list. The alarm list is rebuilt after power on.
Each alarm represents an event. For this reason, the time at which an alarm occurs and disappears
again is recorded in the event list.
An alarm that is present is additionally shown in the status bar and by the red LED.
View
Collective alarm
The following collective signals are created and are available in the digital selector:
• Collective alarm
The signal is active while an alarm is present (the alarm list is not empty).
• Collective alarm acknowledged
This signal is activated when an alarm occurs; it remains active until acknowledged even if the alarm
disappears in the meantime.
(1) Alarm (time and alarm text) (3) Update alarm list
(2) Quit alarm list (4) Acknowledge collective alarm
