4 Electrical connection

4.3 Connection elements

Front USB host interface (without cover)

Back connection elements

Slot 3 (option 3)

Slot 2 (option 2)

Slot 1 (option 1)

Connection element and assignment Connection element and assignment

1. USB device interface 4. Relay 1 (changeover contact)

2.1

2.1,

2.2

Ethernet interface (as a standard feature) or

PROFINET interface (including Ethernet; extra

code)

5. Voltage supply

6. -

15.

Option inputs and outputs (Slot 1 to Slot 3)

3. RS232/RS485 interface
