7 Configuration
7.1 Selectors
The selectors contain signals that are available for configuration on the device or in the setup program.
These are device signals (e.g., analog and digital inputs or internal signals), and signals that are trans-
ferred to the device via an interface (external analog and digital inputs; can also be written using bar-
codes).
7.1.1 Analog selector
Category Signal Description
No selection No signal selected
Analog inputs Analog input 1 to 6 Analog input signal
External analog
inputs
Ext. analog input 1 to 24 Signal of external analog input (via interface)
Flow Flow 1 to 8 Current flowmeter reading
Counter statuses
(current)
Counters (cur.) 1 to 2 Current value of counter or integrator
Math results (ana-
log)
Math (analog) 1 to 6 Results of math formula
ST code analog
outputs
ST analog output 1 to 40 Signal of the analog output from the PLC mod-
ule (application created with ST code)
Batches Text comparison 1 to 10 for
batch 1
Result of the text comparison for the batch line
concerned (text length or index)
Time Time (hours) Hours, minutes, or seconds of the current time
Time (minutes)
Time (seconds)
