3 Mounting
20
3.2 Dimensions
Device
Panel cut-out
Close mounting
Device with terminal cover (accessories)
6
120.9
144
144
136
138
+1
138
+1
Distance between panel cut-outs Horizontal Vertical
Minimum clearance 20 mm 20 mm
Recommended distance (easier mounting of mounting elements) 50 mm 50 mm
128.1 147.6
20.2
109
