11 Annex
276
11.4.2 Texts and process values
Specific control characters can be used to load event texts, process values (external text variables, an-
alog and digital variables), or comment texts (batch recipes).
Once the respective text has been scanned using the control character, the system automatically switch-
es back to barcode input for batch control.
Enter text into event list
%En% = entry into the event list of group n (n = number of group; n = 0 for all groups)
Example: %E1%ABC
The text "ABC" is entered into the event list of group 1.
Example: %E0%DEF
The text "DEF" is entered into the event lists of all groups.
Enter text into external text variable
%Tn% = enter as text into the external text variable n (n = number of variable)
Example: %T1%ABC
The text "ABC" is entered into external text variable 1.
The entered text is available in the text selector.
Control characters and the following text can also be scanned one after another. To do so, only the con-
trol character must be used for the first scan process.
Example for the first scan process: %T1%
The next scanned text is interpreted as text for external text variable 1.
Example for the second scan process: ABC
The text "ABC" is entered into external text variable 1.
Enter float value in external analog variable
%Fn% = enter as float value into external analog variable n (n = number of variable)
Example: %F1%447.6
The float value 447.6 is entered into external analog variable 1.
The entered value is available in the analog selector.
