277
11 Annex
Enter binary value in external digital variable:
%Bn% = enter as binary value into external digital variable n (n = number of variable)
Example: %B1%1
The binary value 1 is entered into external digital variable 1.
The entered value is available in the digital selector.
A scan process allows several values in consecutive variables to be entered.
Example: %B2%101
The binary values 1, 0, 1 are entered as from variable 2 (variable 2 = 1, variable 3 = 0, variable 4 = 1).
Enter text (recipe) in batch report
%Rn% = enter as comment text (e.g. recipe) into the batch report of batch n (n = number of batch)
Example: %R1%ABC
The text "ABC" is entered as comment text into the batch report of batch 1.
The comment text can contain up to 400 characters (20 lines with 20 characters each); it is used to de-
scribe the batch. It can only be displayed using the PC evaluation software PCA3000.
