173
7 Configuration
7.20 Batches
The device supports reporting of one batch. The batch data is recorded along with the channels for the
groups and displayed in batch visualizations.
NOTE!
To use batch reporting at least one group must be active.
7.20.1 General Information
Device dialog box
Parameter
Parameter Selection/settings Description
Batch active Yes, No The selected batch can only be config-
ured if "Yes".
Batch name Batch ... Designation with a maximum length of
15 characters that is used in visualiza-
tions.
Group assign-
ment
Select groups in drop-down menu (set
checkmark).
Batch 1: group 1
Assigned groups are shown with 1 (in
this case: group 1).
Batch start Barcode Start and stop of batch reporting are con-
trolled by a barcode scanner.
Inactive Batch is not recorded.
Control signal Start and stop of batch reporting are con-
trolled by a digital signal.
Touchscreen Start and stop of batch reporting are con-
trolled by a button on the screen.
Control signal Digital selector
No selection
Signal that is used to start (high active)
and stop batch reporting. The parameter
is only available for batch start with "Con-
trol signal".
