JUMO LOGOSCREEN 601 User Manual

245
9 Configuration – in setup program only
9.12.13 Float value entry
Setup dialog box
Parameter
Parameter Selection/settings Description
Destination Variable in which the entered value is written.
No selection No variable selected.
Select variable. Analog selector (external analog input 1
to 24; limit value monitoring 1 to 24: limit
value and switching differential)
Decimal places Select format (drop-down menu). Number of decimal places of the dis-
played value
Minimum value -99999 to 99999 (0) Lower limit of the admissible input range
Maximum value -99999 to 99999 (100) Upper limit of the admissible input range
